The Autel EVO II Dual 640T Rugged Bundle V3 combines radiometric thermal imaging and high-resolution visual imaging in a dual-camera drone platform. The thermal imaging sensor provides 640 × 512 resolution at 30 Hz, a 13 mm lens, up to 16× digital zoom, and subject recognition at distances up to 100 meters. The system also supports 10 thermal color palettes, Picture-in-Picture viewing, and radiometric temperature detection. The integrated visual camera uses a 0.8-inch CMOS sensor capable of capturing 50 MP photos.

Designed for professional field operations, the EVO II Dual 640T Rugged Bundle V3 features 360° obstacle avoidance using 19 sensor groups, Dynamic Track 2.1, and up to 38 minutes of flight time. The bundle includes the 7.9-inch Smart Controller V3, and Autel lists a maximum transmission range of 15 km for this Rugged Bundle configuration.

Applications for the EVO II Dual 640T V3

The Autel EVO II Dual 640T V3 combines radiometric thermal imaging with high-resolution visual imaging for professional aerial operations. Autel identifies applications including line inspection, firefighting, security, search and rescue, chemical plant inspection, and solar inspection. The 640 × 512 thermal imaging system supports central, spot, and regional temperature measurements for evaluating thermal conditions during inspection and monitoring operations.

Thermal analysis features include 10 thermal color palettes, temperature alarms, isotherms, image enhancement, and Picture-in-Picture viewing, which combines thermal and visual imagery for side-by-side data interpretation. Autel's IRPC thermal analysis tool also supports importing thermal images, analyzing and editing temperature measurements, and generating reports for additional review and documentation.

Ultra-Sensitive Visual Imaging System

Key Features:

• Dual-Camera Imaging: Combines a 640 × 512 radiometric thermal camera with a 50 MP visual camera.
• Thermal Imaging: 640 × 512 resolution at 30 Hz with a 13 mm thermal lens and up to 16× digital zoom.
• Radiometric Temperature Measurement: Supports central, spot, and regional temperature measurements.
• Thermal Analysis Tools: Includes 10 thermal color palettes, Picture-in-Picture viewing, temperature alarms, isotherms, and image enhancement.
• 50 MP Visual Imaging: Features a 1/1.28-inch (0.8-inch) RYYB CMOS sensor with Moonlight Algorithm 2.0.
• Visual Zoom: Supports up to 16× digital zoom and 4× lossless zoom.
• 360° Obstacle Avoidance: Uses 19 sensor groups for omnidirectional obstacle sensing.
• Dynamic Track 2.1: Supports target tracking during flight operations.
• Maximum Flight Time: Up to 38 minutes.
• Transmission Range: Up to 15 km.
• Smart Controller V3: Includes a 7.9-inch integrated display with up to 2,000 nits of brightness.
