The Emlid Reach RX2 is a lightweight, all-band RTK GNSS rover with tilt compensation designed for high-accuracy field data collection. It provides 672 GNSS channels and tracks GPS, GLONASS, Galileo, BeiDou, QZSS, and NavIC signals. RTK positioning accuracy is specified at 7 mm + 1 ppm horizontally and 14 mm + 1 ppm vertically, while tilt compensation provides RTK + 2 mm + 0.3 mm/° performance. At 280 g, the RX2 is designed specifically for use with NTRIP corrections and connects to compatible iOS and Android devices through Bluetooth.

The Reach RX2 supports applications across construction, utilities, GIS, landscaping, urban planning, asset mapping, and terrestrial scanning. Emlid identifies workflows including layout and reference point placement, utility and site-feature documentation, slope and grade measurements, property-corner location, road and pipeline centerlines, earthwork measurements, and as-built documentation. The RX2 also integrates with applications including ArcGIS Field Maps, QField, Survey123, Mergin Maps, and PIX4Dcatch for high-accuracy GIS and scanning workflows.

• All-band RTK GNSS rover with tilt compensation
• 672 GNSS tracking channels
• GPS, GLONASS, Galileo, BeiDou, QZSS, and NavIC signal tracking
• RTK accuracy of 7 mm + 1 ppm horizontal and 14 mm + 1 ppm vertical
• Tilt compensation performance of RTK + 2 mm + 0.3 mm/°
• Typical convergence time of approximately 5 seconds
• Designed for NTRIP-based RTK corrections
• RTCM3 correction data support
• NMEA positioning data output
• Bluetooth 4.2 connectivity
• Apple MFi certified for iOS connectivity
• Compatible with iOS and Android devices
• Compatible with ArcGIS Field Maps, QField, Survey123, Mergin Maps, and other GIS applications
• 280 g receiver weight
• Up to 16 hours of battery operation
• USB Type-C charging
• IP68 ingress protection rating
• Operating temperature range of -20°C to +65°C
• Quick-release and 5/8"-11 UNC mounting interfaces
