The Phase One iXM-GS120 is a 120-megapixel medium-format geospatial camera built around a CMOS global shutter sensor with a resolution of 12,768 x 9,564 pixels. Its electronic global shutter supports exposure times up to 1/16,000 second, allowing the camera to capture fine details of rapidly moving objects. The compact camera is designed for tight integrations, including space-constrained pods and gimbals, making it suitable for professional aerial and geospatial imaging applications that require high-resolution data capture.

The iXM-GS120 provides an 80 dB dynamic range, RGB and achromatic color options, and a continuous frame rate with previews of up to 2 fps. Phase One RSM and RS lens mounts support different imaging configurations, while 10G Ethernet, USB 3, Phase One SDK, MAVLink API, and CFexpress storage up to 1 TB support integration into professional imaging systems. The electronic global shutter also eliminates the need for a mechanical shutter, which Phase One identifies as supporting a robust design with low-to-no maintenance.

• 120 MP CMOS global shutter sensor
• 12,768 x 9,564 pixel resolution
• Electronic global shutter
• Maximum shutter speed of 1/16,000 second
• 80 dB dynamic range
• RGB and achromatic color options
• 3.45 µm pixel size
• 43.9 x 32.9 mm sensor size
• 4:3 aspect ratio
• Continuous frame rate with previews up to 2 fps
• Phase One RSM and RS lens mounts
• 10G Ethernet Fiber/Copper and USB 3 image interfaces
• Phase One SDK and MAVLink API
• CFexpress internal storage up to 1 TB
• Lightweight, compact design for tight integrations
• Electronic global shutter requires no mechanical shutter
