The PHASE ONE IXM-100MP GEOSPATIAL CAMERA is a cutting-edge medium format aerial imaging solution engineered for UAV-based mapping, surveying, and inspection missions. Featuring a 100-megapixel CMOS sensor with backside illumination technology, the camera delivers exceptional image quality, high light sensitivity, and extended dynamic range. Its robust, lightweight design allows seamless integration with a wide range of drone platforms, enabling professionals to capture large-area, high-resolution imagery in diverse flight conditions. The IXM-100MP supports a selection of high-performance RSM lenses from 35mm to 300mm, each optimized for sharpness and coverage, making it suitable for both detailed asset inspections and precision-driven mapping projects.

This camera is ideal for applications such as infrastructure inspection, power line monitoring, bridge and wind turbine surveys, forestry, agriculture, and geospatial mapping. The integrated leaf shutter enables high capture speeds up to 3 frames per second and shutter speeds up to 1/2500 second, ensuring blur-free results even in dynamic environments. Advanced features like geotagged image capture, weatherproof IP53 rating, and compatibility with remote control and flight planning software support reliable operation in challenging field conditions. The IXM-100MP empowers organizations to streamline aerial data collection, reduce operational risks, and achieve superior results in photogrammetry, 2D and 3D mapping, and predictive maintenance.

Key Features:

• 100-megapixel CMOS sensor with backside illumination for high sensitivity and dynamic range
• Medium format resolution: 11,664 x 8,750 pixels
• Supports RGB and achromatic color options
• Lightweight and robust design for easy drone integration
• High capture speed: up to 3 frames per second, shutter speed up to 1/2500 second
• Wide lens compatibility: RSM lenses from 35mm to 300mm, fixed and motorized focus options
• Integrated leaf shutter for reliable performance in varied flight conditions
• Weatherproof IP53 rating for outdoor operation
• Geotagged image capture and advanced camera control SDK
• Ready for remote updates and integration with flight planning software
• Ideal for mapping, surveying, inspection, asset management, and predictive maintenance
