The Autel EVO Max 4N is an enterprise drone designed for low-light and nighttime operations. Its FusionLight Camera 4N integrates a 2.3 MP starlight night-vision camera with 0.0001 lux ambient-light recognition, a 50 MP ultra-sensitive wide-angle camera, a 640 × 512 thermal camera, and a laser rangefinder with a measuring range of 5 to 1,200 meters. The starlight and thermal cameras support nighttime object identification and tracking, including heat sources, moving individuals, and vehicles in extremely low-light conditions.
Autel Autonomy technology supports global path planning, 3D scene reconstruction, autonomous obstacle avoidance, and return-to-home in complex environments. High-precision visual navigation uses SLAM technology to support stable indoor and outdoor flight when satellite signals are obstructed or weak. The aircraft also features 720° sensing and obstacle avoidance, A-Mesh networking, a hot-swappable battery, up to 42 minutes of flight time, and 15 km image transmission. Manufacturer-identified applications include power line inspection, emergency search and rescue, law enforcement, geographical surveying, and firefighting rescue.
EVO MAX 4N
The Autel EVO Max 4N combines the FusionLight Camera 4N with Autel Autonomy technology for low-light, night-time, and complex flight operations. Its imaging system includes a super starlight-level night vision camera with 0.0001 lux ambient-light recognition, an ultra-sensitive wide-angle camera, thermal imaging, and laser range finding capabilities.
| |
|
- 720° Sensing and Obstacle Avoidance using binocular fisheye vision and millimeter-wave radar
- Superior Anti-Interference Capability
- High-Precision Visual Navigation using SLAM technology
- A-Mesh Networking
- Super Starlight-Level Night Vision Camera with 0.0001 lux ambient-light recognition
|
|
- Nighttime Object Identification and Tracking using starlight and thermal imaging
- Hot-Swappable Battery
- 15 km Image Transmission Distance
- Up to 42 Minutes Maximum Flight Time
- IP43 Protection Rating, available as a custom service
|
|
Explore the Night
|
|
Thermal Camera
- Resolution: 640 × 512
- Focal Length: 9.1 mm
- Digital Zoom: 16×
- Temperature Range: -20°C to 150°C / 0°C to 550°C
|
Laser Rangefinder
-Measuring Range: 5 to 1,200 m (16.4 to 3,937 ft)
- Measurement Accuracy: ± (1 m + D × 0.15%)
- D = Measurement Distance
|
|
Super Starlight-Level Night Vision Camera
- Resolution: 2.3 MP
- Ambient-Light Recognition: 0.0001 Lux
- ISO: 440,000
|
Ultra-Sensitive Wide-Angle Camera
- Resolution: 50 MP
- Sensor: 1/1.28-inch CMOS
- Aperture: f/1.9
- Field of View: 85°
- Equivalent Focal Length: 23 mm
|
|
No Blind Spots
720° Obstacle Avoidance
The Autel EVO Max 4N combines binocular fisheye vision with millimeter-wave radar for 720° sensing and obstacle avoidance. This multi-sensor perception system supports obstacle awareness during flight in complex operating environments.
Superior Anti-Interference Capability
The EVO Max 4N features high-precision visual navigation designed to support stable and reliable flight when satellite signals are obstructed, weak, or affected by strong signal interference. SLAM visual navigation provides high-precision indoor and outdoor positioning when satellite-based navigation is limited.
Professional Use Cases for the EVO Max 4N
| |
Law Enforcement
The Autel EVO Max 4N supports law enforcement operations with starlight and thermal imaging for nighttime object identification and tracking. The manufacturer states that the system can identify and lock onto heat sources, moving individuals, and vehicles for high-altitude tracking in extremely low-light conditions.
|
|
Emergency Search & Rescue
The FusionLight Camera 4N combines starlight night vision, thermal imaging, a wide-angle camera, and laser rangefinding to support emergency search and rescue operations, including missions conducted in extremely low-light environments.
|
|
| |
Firefighting & Rescue
Autel identifies firefighting and rescue as an application for the EVO Max 4N. Its FusionLight Camera 4N includes a 640 × 512 thermal camera with a temperature measurement range reaching up to 550°C, along with visual and laser rangefinding sensors.
|
|
Power Line Inspection
Power line inspection is a manufacturer-identified application for the EVO Max 4N. The aircraft combines autonomous flight planning, high-precision visual navigation, thermal imaging, and other integrated sensors for aerial inspection operations.
|
|
| |
Geographical Surveying
The EVO Max 4N supports geographical surveying applications using Autel Autonomy technology for global path planning, 3D scene reconstruction, autonomous obstacle avoidance, and return-to-home capabilities in complex environments.
|
|
Key Features:
- FusionLight Camera 4N with starlight night vision, ultra-sensitive wide-angle imaging, thermal imaging, and laser rangefinding
- Super Starlight-Level Night Vision Camera with 0.0001 lux ambient-light recognition
- 720° Sensing and Obstacle Avoidance using binocular fisheye vision and millimeter-wave radar
- High-Precision Visual Navigation using SLAM technology when satellite signals are obstructed or weak
- Autonomous Flight Planning with global path planning, 3D scene reconstruction, autonomous obstacle avoidance, and return-to-home capabilities
- A-Mesh Networking for communication across multiple connected devices
- Superior Anti-Interference Capability for complex operating environments
- Hot-Swappable Battery support
- 15 km Image Transmission Distance
- Up to 42 Minutes Maximum Flight Time
- IP43 Protection Rating, available as a custom service
