The PSP VORTEXX Series R 120/240V Type 1 Single Phase Surge Protector is designed to protect electrical panels and connected equipment from transient voltage surges caused by lightning, utility switching, and internal load events. Built for service entrance and downstream panel applications, this surge protective device supports single-phase 120/240V systems with a 3W+G wiring configuration. It is commonly installed in commercial, industrial, and utility environments where reliable surge suppression is required to reduce equipment stress and unplanned downtime.

This unit incorporates thermally protected MOV suppression, capacitive filtering, and a gas discharge tube to manage high-energy surge events while maintaining system stability. With a maximum discharge current of 120kA per phase and EMI/RFI noise filtration rated at -40 dB, the VORTEXX Series R supports sensitive electronic loads and power distribution equipment. The cast aluminum NEMA 4X enclosure allows for indoor or outdoor installation, and visual and audible status indicators provide clear operational feedback for maintenance personnel.

Key Features:

• Type 1 surge protective device for 120/240V single-phase electrical systems
• Maximum discharge current of 120kA per phase and nominal discharge current of 20kA
• Thermally protected MOV suppression with capacitive filtering and gas discharge tube
• EMI/RFI noise filtration rated at -40 dB for improved power quality
• LED indicator and audible alarm for surge protection status monitoring
• NEMA 4X, IP65/IP66 rated cast aluminum enclosure for indoor or outdoor installation
• UL 1449 5th Edition Type 1 Listed and UL listed to U.S. and Canadian safety standards
• 200kA short circuit current rating (SCCR)
• 36-inch #10 AWG leads for connection flexibility
• Repositionable face cover for label orientation and optional mounting or flush-mount accessories
